Difference between Weaving and Embroidery: A Tale of Two Textile Traditions

People usually get confused between two textile industry terms weaving and embroidery. That’s when they access the internet to understand the difference between weaving and embroidery.

Weaving and embroidery are two different techniques of using threads to create very distinct products. Weaving creates fabric and embroidery creates thread designs over fabric. The patterns on a weaved fabric are sewn at the time of fabric production. While embroidery is sewed after the fabric production over it.

Well, to understand the difference between weaving and embroidery you need to understand both terms first. So, let’s move on this informative blog that will clear up your concept about weaving and embroidery.

What is Weaving?

It’s an Age-Old Technique of Thread Interlacing

Weaving is one of the most ancient technologies to fabric manufacture fabrics of different shades and colors. It is the process of braiding two essential types of yarn: the warp and weft.

Warp threads are like the backbone of weaving. They are the long, vertical threads that provide the foundational structure for the fabric. They are stretched tightly on a loom, ensuring the strength and stability of the fabric.

In contrast, the wefts are horizontal threads that move back and forth, weaving between the warps. It creates the patterns and adds the design details to the fabric.

When weaving, the process begins with the warp threads in place. It’s like creating the iron structure of the building. Then weft threads are woven over and under these foundations in a specific pattern. After this braiding weft and wrap, thread by thread, pass by pass final fabric is created.

Hence, together, these two elements collaborate in the weaving process, creating beautiful weave patterns. However, there are three basic weave patterns:

  • plain weave
  • satin weave
  • twill weave


The Technique Of Weaving:

Weaving work on over and under techniques. It is a methodical process that starts with the preparation of the warp and weft threads. However it’s done using a modern machine called a loom. It has three key actions.

  • Shading: This separates the warp threads, creating a space where the weft can pass through.
  • Picking: During this step, the weft is propelled across the loom, adding the creative element to the fabric.
  • Beating Up or Battening: The reed pushes the weft threads tightly against the fabric, giving the fabric its final texture and look.

First step is to mount the warp threads vertically on a loom. It creates a tightly stretched network of threads. Loom then uses warp threads to form the fabric’s structural foundation.

The process starts with long stitches in one direction. It could be either vertical or horizontal. But, vertical direction is preferred by expert weavers to create thread foundation. The action is then repeated several times.

Read More: Best Fabrics For Embroidery Patches

On the other hand, the weft threads are rolled onto a shuttle or bobbin. Later they are woven horizontally to introduce color and patterns.

Weavers ensure that each pass of the weft is interlaced over wrap thread and under the next in the same manner. This guarantees the correct tension in the warp and weft threads. As a result, you get a well-structured woven fabric.

What Is Embroidery?

It’s The Art of Stitching designs over fabric

Where weaving creates fabrics, Embroidery is the technique of using a needle and colorful thread to sew beautiful patterns and designs on those fabrics. It’s the art of creating designs to make plain fabric look stylish and unique. People have been doing this for a very long time to make clothes, blankets, and other things more attractive.

Besides, unlike weaving, there are various types of threads used in embroidery. It includes:

  • Embroidery Floss
  • Pearl Cotton
  • Crewel Wool
  • Metallic Thread
  • Silk Thread
  • Rayon Thread
  • Ribbon

Read More: How to change jpg to DST Embroidery format

Moreover, weaving only includes thread patterns in three basic forms. Since embroidery is a designing technique it offers versatile options under the domain of both digital machine embroidery and hand embroidery. These patterns are:

  • Cross-Stitch
  • Satin Stitch
  • Chain Stitch
  • Running Stitch
  • French Knot
  • Crewel Stitch
  • Stem Stitch
  • Backstitch
  • Bullion Knot
  • Long and Short Stitch
  • Whipped Backstitch

Embroidery Technique: How is it different from weaving?

In comparison, the process of weaving embroidery is a difficult task. Even though it uses less thread and time it needs accuracy and complicated design drawing. Different types of embroidery involve different processes.

For instance if you want to go for machine embroidery, you will have to go for embroidery digitizing first. After that you will have to choose between different fabrics for embroidery. Later you can feed those digital designs to embroidery machines and get the design over your t-shirt, linen or cap.

Besides, embroidery can also be done without modern machines. It’s a slow process that includes several steps. The first step is to place your fabric in an embroidery hoop to keep it steady. Then the embroiderers choose embroidery thread. Later they thread needles and start outlining the design with stitches like the backstitch or running stitch. After that the outline is filled with stitch thread by thread.

Moreover, it allows you to be versatile and use various stitches like satin stitch, French knots, or cross-stitch. And, then comes the last step of securing the thread at the back of the fabric.

Read More: How To Convert Emb File to Dst

Comparison Between The Cost And Usability of Embroidery And Weaving:

Now that you know, embroidery and weaving are distinct textile techniques. Let’s understand that each technique has unique cost structures and usages that cater to a variety of needs in the textile industry. So, let’s compare the cost and usage difference between embroidery and weaving side by side.


When choosing between embroidery and weaving, the cost is a key factor. Weaving is often more cost-effective when making large amounts of fabric. This is because it uses high-speed machines that can make lots of the same fabric quickly. You don’t need many special tools, which keeps costs down.

Embroidery, on the other hand, can be more expensive. It’s detailed and needs a lot of time and skill. Hand embroidery, especially, involves skilled artists spending a lot of time crafting intricate designs. Machine embroidery is cheaper for big production but still requires you to pay for setting up designs and maintaining special machines. The cost of embroidery also goes up if you use high-quality thread or very complex designs.

Read More: Guide for Digitizing 3D Puff Embroidery


The choice between embroidery and weaving also depends on how you want to use the fabric. Weaving is excellent for making lots of fabric for things like clothes, furniture, and everyday items. It’s great for mass production. You’ll often find plain weaves, satin weaves, and twill weaves in this kind of fabric.

Embroidery is better for decorative and designing fabric. People use it to add special touches to clothing, accessories, and home decor. It’s very versatile and can create unique designs. It’s also great for adding logos and custom details to clothes.

Final Words:

Now you know that weaving and embroidery both need needles and threads but both are completely different. You need to know weaving is great for mass-producing structured fabrics. Whereas, embroidery is all about adding artistic and individual touches to textiles. Hence, the choice between the two depends on what you want to create and the level of detail you aim for.
